◆的產品特質 Product features
1. 設計有新意,外觀簡約時尚整齊,環保型作用(yong)好;
2. 可(ke)控式(shi)漩風轉移器,能(neng)將可(ke)以(yi)選擇研磨材料(liao)與細小粉塵爆炸轉移,好的研磨材料(liao)再利用;
3. 主要(yao)的零元件適用好的進(jin)囗的加工零件,操作(zuo)時間(jian)長;
4. 粗加(jia)工軸類外(wai)觀不光滑;
5. 多工裝夾具定制;工作員可時候工作噴砂。會按照客要,必選擇手動或全自動 ;可按投資者規定定制!
1. Novel design , beautiful shape, good environmental protection effect;
2. Adjustable cyclone separator, can be used with tiny dust separation, good abrasive continue to use;
3. The main components uses the high quality import parts, long service life;
4. Machining surface evenly;
5. Program design; An operator can also operate sandblasting. we can choose manual or automatic according to customer needs.
◆適宜區間 Applicable scope
家具(ju)板材(cai),計算機設備(bei)殼,影響(xiang)開關(guan)按(an)鈕,雞蛋三明(ming)治(zhi)烤盤等(deng)垂直面(mian)及方(fang)體(ti)軸類(lei)的噴(pen)砂(sha)激光加工。
Plate, the computer case, music panels, sandwich baking dish wait for plane and workpiece of sandblasting processing.
◆主要的技能運作 Main technical parameters
|
絲機具體型(xing)號 Model |
STR-多工位輸送式噴砂機 |
|
組裝機寸尺 Complete machine size(mm) |
3000×1000×1700 |
|
事業空間區域(yu) Work space(mm) |
2000×1000×800 |
|
外(wai)傳輸長度 Conveying the size(mm) |
500×1000×1000(2件) |
|
布袋除塵箱的尺寸 Dedust box sizes(mm) |
600×600×1800 |
|
分離器主軸(zhou)電機 Separator motor |
220V 50HZ 550W |
|
分割器排(pai)風量 Separator air volume |
8.5m3/min |
|
再壓縮環境源 Compressed air source |
2-8bar(kg/cm2) |
|
噴槍(qiang) Spray gun |
2把 |
|
照明 Floodlight |
兩盞30W防火燈 |
|
機設(she)備自重 Machine weight |
550kg |
